/ AKLAS COMBINE HARVESTER

ENGINEERED SPECIFICATIONS

Uncompromised mechanical, dimension, and capacity data for fleet owners and agricultural contractors demanding field-ready uptime in intense multi-crop cycles.

CORE PERFORMANCE

Power & Transmission

Heavy-duty diesel powertrains selected for high-yield dual-crop harvesting operations.

Engine Assembly

Drive & Brakes

Field Capacity

Ashok Leyland / Volvo Eicher option. 101 HP to 137 HP, 6 cylinders, water-cooled with dry air cleaner built for dusty Punjab fields.

4 forward and 1 reverse gear transmission. Max speed of 35 Km/h. Equipped with hydraulic-assisted disc brakes for precision control.

Wheat throughput of 3.5 to 4.5 acres per hour. Paddy throughput of 2.5 to 3.5 acres per hour under demanding mud conditions.

Low-angle detailed close-up of a heavy-duty steel harvester cutter bar, metallic grey steel, sharp hazard red accents, dramatic industrial lighting.
Low-angle detailed close-up of a heavy-duty steel harvester cutter bar, metallic grey steel, sharp hazard red accents, dramatic industrial lighting.
HEAVY-DUTY BUILD

Chassis & Capacity

High-capacity steel construction designed to minimize downtime during tight harvesting windows.

Operating Metrics

Total operating weight of 9200 Kg supported by high-traction front 18.4-30 and rear 9.00-16 agricultural tires. Designed with 350 mm ground clearance to navigate wet paddy terrain.

Cutter bar working width of 4340 mm operating at 853 strokes per minute. Features a 2010 Kg grain tank and a 380 Litre fuel tank to maximize continuous field run-time.
